Keysight M8199B Ultra-High Performance Arbitrary Waveform Generator: Technical Analysis and Cutting-Edge Applications

The Keysight M8199B Arbitrary Waveform Generator (AWG) is one of the most powerful signal generation devices in the industry today, with a sampling rate of 256 GSa/s and an analog bandwidth of >80 GHz.

Keysight M8195A 65GSa/s Arbitrary Waveform Generator: A Benchmark Solution for High-Precision Signal Generation Technology

In microwave RF, high-speed digital communications and cutting-edge scientific research, the accuracy and bandwidth of signal generation directly determine the upper limit of the test system, Keysight M8195A, as a new generation of 65GSa/s Arbitrary Waveform Generator, builds an industry-leading performance benchmark with a combination of hard-core parameters such as 25GHz analog bandwidth, 14-bit vertical resolution, and 8GB of waveform storage depth per channel. performance benchmark.

keysight M8195A Broadband Pulse Radar Test Solution

The Wideband Pulse Radar Test Solution combines commercial off-the-shelf COTS modular hardware and software from Keysight Technologies, KJ Microwave, and Virginia Diodes to provide a flexible, multi-channel test bench for radar waveform generation and analysis.
Segmented memory acquisition in the digitiser uses a circular acquisition buffer with a minimum inter-segment dead time of 300 ns. This allows, for example, the capture of up to 64 million repetitive radar signals at relatively large repetition intervals.

Keysight E8363A Network Analyzer: High-Performance RF and Microwave Testing Solution

Keysight E8363A Vector Network Analyzer is a high-performance RF test instrument with a frequency range of 10 MHz to 40 GHz (extendable to 67 GHz). It supports S-parameter measurements, time-domain analysis (TDR), and noise figure testing. Featuring >130 dB dynamic range and ±0.03 dB amplitude accuracy, it is ideal for device characterization in 5G, radar, semiconductor and other fields. Offering 2/4-port configurations with SOLT/TRL calibration capabilities, and equipped with a touchscreen and GPIB/LAN interfaces, it is well-suited for both R&D and production line testing.

AQ6370D Spectrum Analyzer: Accurate Measurements with DWDM System

With the rapid advancement of 5G networks, optical communication technology has ushered in unprecedented changes. Dense wavelength division multiplexing (DWDM) systems have become the core of modern fiber optic communication networks due to their efficient data transmission capability and spectrum utilization. However, the dense channel distribution and high-speed data transmission in DWDM systems place higher requirements on the optical spectrum analyzer (OSA).

Anritsu MP2110A MP1900A Difference? BERTWave Eye Mapper Oscilloscope All-in-One

Anritsu demonstrated that its BERTWave MP2110A and MP1900A 56G PAM4 BERT can be combined to provide TDECQ measurements for 400Gbps optical chips and modules. This demonstrates that the MP1900A is a related product to the MP2110A and that the two can work together for specific types of testing.

About MS9740A Anritsu Anritsu Spectrum Analyser Essentials, Bookmark this post!

The MS9740A is a spectrum analyser manufactured by Anritsu for analysing optical signals in the wavelength range of 600 to 1750 nm.With its high-performance optical resolution and high-speed measurement capability, the MS9740A is capable of evaluating up to 300 channels of data and displaying the information required for WDM signal analysis, such as centre wavelength, level, signal-to-noise ratio, and so on.

About MS9740B Anritsu Anritsu Spectrum Analyser Essentials, Bookmark this post!

The MS9740B Spectrum Analyser is marketed primarily to the optical communications field where high accuracy, speed and wide dynamic range are required. Target user groups include, but are not limited to, R&D personnel in the optical communications industry, engineers manufacturing and evaluating 850 nm band VCSEL modules, and professionals conducting optical research and development.

DSOV334A Keysight Infiniium V-Series Oscilloscopes

Keysight Infiniium V-Series oscilloscopes offer industry-leading accuracy, 33 GHz analogue bandwidth, 4 analogue channels, sampling rates up to 80 GSa/s and 2 Gpts of acquisition memory for more complete signal trace capture.

About AQ6370D Spectrum Analyser Essentials, Bookmark it and save it!

The AQ6370D is a spectrum analyser manufactured by Yokogawa Electric Corporation and is mainly used in the telecommunication field. It offers a wavelength range of 600 nm to 1700 nm for a wide range of testing needs. The unit is known for its high performance and accuracy, with high wavelength accuracy of ±0.01 nm and high wavelength resolution of 0.02 nm.

N7779C keysight Tunable Laser Source Description

The new N7779C Base Series tunable laser source, like the other new N777xC models, is ideal for cost-effective testing of broadband optical devices because of its ability to step quickly to discrete wavelengths with resolutions up to 0.1 pm and typical wavelength repeatability of ±3 pm. Short wavelength setup times (e.g., 300 ms) enable fast step scanning. Like other laser sources in the N777xC family, it delivers peak output power in excess of +12 dBm and low spontaneous emission levels. With power stability of ±0.01 dB per hour, it can also be used as a static local oscillator with a wide tuning range for receiver testing or transmission experiments.

N7714A keysight keysight Single Port Tunable Laser Source System Description

The Keysight N7711A and N7714A tunable laser sources are available with a single port and four ports, respectively, in either C-band or L-band wavelength ranges. With narrow linewidths and finely adjustable bias grids, they are ideal for testing the real-world load performance of the latest launch systems. As with all other Yesotech tunable laser sources, all models can reach any wavelength point within their specified wavelength range.

Products News-Megate - General Electronic Test and Measurement Instruments Technology Services, Inc.

Products News-Megate - General Electronic Test and Measurement Instruments Technology Services, Inc.

Products News-Megate - General Electronic Test and Measurement Instruments Technology Services, Inc.

Products News-Megate - General Electronic Test and Measurement Instruments Technology Services, Inc.

DAQ970A data collector from keyshight replace the 34970A?

The DAQ970A is a new data collector that replaces the 34970A. The DAQ970A has a new generation of high-speed digital multimeter module built in, with the same 6.5-bit resolution, and thanks to the new ADC technology, the noise floor and accuracy are slightly higher than the old 34970A.

How to use Agilent 34970A, the instrument self-test

How does the Agilent 34970A data acquisition instrument self-test at power-on? As the GPIB and RS232 interfaces are rarely used, we often forget or even fail to use the power-on self-test function. The Agilent 34970A is a high-performance, low-cost data acquisition and switching mainframe that is well suited for data logging, data acquisition, and general switching and control applications. It is a half-rack-wide host, with an internal 61/2-bit (22-bit) digital voltmeter, and three slots on the back to accept a combination of switching and control modules.

34970A Data Collector Getting Started Guide and Basic Explanation

The 34970A Agilent Data Acquisition/Datalogger Switching Unit consists of a 3-slot mainframe and a built-in 6 1/2-bit digital multimeter. Each channel can be individually configured to measure one of 11 different functions, thus neither increasing cost nor eliminating the need for complex signal conditioning accessories.

N1092A keysight DCA-M sampling oscilloscope (single optical channel)

The N1092A keysight is a highly accurate, low-cost optical waveform analysis solution for the DCA-M sampling oscilloscope (single optical channel), including solutions offering 8.4 to 64 Gbaud, very low noise and jitter, fast sampling rates that enable high throughput, and integrated clock recovery.

How to test OLT with 81250A Agilent?

The Agilent 81250A OLT test requires two ONU signals, while the ONU requires an enable signal, so four signals are required. In addition, if it is a GPON system OLT devices, also need a Reset signal, a total of five signals are required.

N1092E keysight 28/45 GHz (2 optical channels) and 50 GHz (2 electrical channels) DCA-M sampling oscilloscopes

The Keysight N1092E is a DCA-M sampling oscilloscope with one optical channel and two electrical channels. The highly accurate, low-cost optical/electrical waveform analysis solution includes solutions that offer 8.4 to 64 Gbaud, very low noise and jitter, and fast sampling rates that enable high throughput.

MS9740B Anritsu Spectrum Analyzer

The MS9740B spectral analyzer achieves an overall test speed of less than 0.2 seconds from waveform scanning to waveform resolution and data transfer to external control devices, and with enhanced VBW settings (1 kHz and 200 Hz) commonly used by users, the MS9740B not only maintains the same measurement sensitivity as previous models, but also reduces measurement time by 50%, helping to further improve user productivity.

N7745C keysight Yester multi-port optical power meter (8 channels)

The N7745C is a replacement for the Yeste N7745A optical power meter, which is deeply optimized for high measurement throughput and can be used to characterize multi-port optical devices such as multiplexers, PON splitters, wavelength selective switches (WSS) and ROADMs. The instrument features high-speed measurement data acquisition capabilities and a faster data interface, and uses dual-port RAM to allow simultaneous measurement and reading of results without interrupting either operation.

MP2100B Anritsu BERTWave™ (10G BERT, sampling oscilloscope)

The MP2100B Anritsu BERTWave is an all-in-one tester with built-in BERT and sampling oscilloscope for supporting optical module evaluation, including BER measurement, eye diagram template testing and eye diagram analysis.
