FPS R&S

Spectrum Analyzer
• Frequency range up to 4/7/13.6/30/40 GHz
• Up to 160 MHz signal analysis bandwidth
• 0.4 dB level measurement uncertainty (up to 7 GHz)
• GSM/EDGE (including EDGE Evolution)
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.

FSVA3000 R&S

Spectrum Analyzer
• Frequency range from 2 Hz to 4/7.5/13.6/30/44/50/54 GHz
• Analysis bandwidth up to 1 GHz
• SSB phase noise at 10 kHz offset (1 GHz): -127 dBc/Hz
• Multi-touch GUI, SCPI logger, and event-based operation support
• Multiple analogue and digital signal analysis options, including 5G NR signal analysis
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.

FSW R&S

Spectrum Analyzer
• Superior phase noise and sensitivity on the market
• 8.3 GHz internal analysis bandwidth
• 800 MHz real-time analysis bandwidth
• SCPI logger simplifies code generation
• High dynamic range for excellent EVM performance
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.

FSW85 R&S®

Signal Analyzer
• Superior phase noise and sensitivity on the market
• 8.3 GHz internal analysis bandwidth
• 800 MHz real-time analysis bandwidth
• SCPI logger simplifies code generation
• High dynamic range for excellent EVM performance
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.

N5193A keysight

Signal Analyzer
• 10 kHz frequency resolution
• 100 µs switching speed (up to 31.6 GHz); 500 µs (up to 40 GHz)
• +10 to -10 dBm amplitude range
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.

N5191A keysight

Signal Analyzer
• 10 kHz frequency resolution
• 100 µs switching speed (up to 31.6 GHz); 500 µs (up to 40 GHz)
• +10 to -10 dBm amplitude range
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.

N9020B keysight

Signal Analyzer
• Wide frequency range of 10 Hz to 50 GHz and analysis bandwidth of up to 160 MHz allows you to see more signal detail
• Hardware-accelerated power measurement, fast display update rate, fast cursor peak search, and fast scan features dramatically reduce test time
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.

N9030B keysight

Signal Analyzer
• Wide frequency range of 2 Hz to 50 GHz and analysis bandwidth of up to 510 MHz enables analysis of more signals
• Spurious-free dynamic range (SFDR) of up to 75 dB allows you to easily view small signals masked by large signals
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.
Signal Analyzer | Mega- Test and Measurement Technology Services, Inc.

N9040B keysight

Signal Analyzer
• View more complex signals with a broader (up to 1 GHz), deeper view
• Measure the spectral purity of your design with ultra-low phase noise and spurious-free dynamic range of up to 78 dBc over a 510 MHz bandwidth
/
