AQ6370D YOKOGAWA

Spectral Analyzer
• Wavelength range: 600~1700nm
• High wavelength accuracy: ±0.01nm
• High wavelength resolution: 0.02nm
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.

MS9740B Anritsu

Spectral Analyzer
Same key features and performance as its predecessor, supporting a variety of production line environments
• Wide bandwidth (600 nm to 1750 nm) for evaluation of all optical active devices
• 9 application menus for measurements of LD modules, WDM, etc.
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.

86142B Keysight

Spectral Analyzer
• Built-in test application
• 10 pm wavelength accuracy
• Fast double sweep method
• Coverage of S, C and L bands
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.

AQ6375E YOKOGAWA

Spectral Analyzer
・Lineup of 3 models [Standard, Extended and Limited]
・Covers wavelengths
1200 to 2400 nm [Standard, and Limited]
1000 to 2500 nm [Extended ]
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.

771/772 Bristol

Spectral Analyzer
• Spectral resolution as high as 2 GHz
• Wavelength accuracy as high as ± 0.0001 nm
• Optical rejection ratio > 40 dB
• Operation available from 375 nm to 12 μm
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.

AQ6374 Yokogawa

Spectral Analyzer
• Wavelength range: 350 to 1750nm
• High wavelength accuracy: ±0.05nm
• High wavelength resolution: 0.05 to 10 nm
• Wide dynamic range: 60dB (peak ±1.0nm)
• Wide level range: +20 to -80dBm
• Fast measurement: 0.5 sec. (100nm span)
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.

AQ6374E Yokogawa

Spectral Analyzer
• Wide wavelength range: 350 - 1750 nm
• High wavelength resolution: 0.05 nm (full wavelength range)
• High wavelength accuracy: ±0.05 nm (633/1523 nm), ±0.2 nm (350 - 1750 nm)
• Close-in dynamic range: 60 dB (λPK ±1 nm)
• Sensitivity: -80 dBm (900 - 1600 nm), -70 dBm (400 - 900 nm)
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.

AQ6317C ando

Spectral Analyzer
• High wavelength resolution Maximum wave length resolution: 15 pm.
• Wide dynamic range Over 70 dB at peak +/-0.4 nm Over 60 dB at peak +/-0.2 nm.
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.
Spectral Analyzer | Mega- Test and Measurement Technology Services, Inc.

AQ6370E YOKOGAWA

Spectral Analyzer
• Wavelength range: 600 to 1700 nm
• Wavelength accuracy: ± 0.008 nm typ.
• Wavelength resolution: 0.02 nm
• Near-range dynamic range: 78 dB typ.
/
