M8195A keysight
Arbitrary Waveform Generator
• Sampling rates up to 65 GSa/s
• High channel density: 1, 2 or 4 channels per module, up to 16 channels on 4 modules can be synchronized using the M8197A multi-channel synchronization module
• Built-in frequency and phase response calibration
• High channel density: 1, 2 or 4 channels per module, up to 16 channels on 4 modules can be synchronized using the M8197A multi-channel synchronization module
• Built-in frequency and phase response calibration
U2761A keysight
Generator
• 20 MHz sine and square waves
• Ramp, triangle, pulse and DC waveforms
• 14-bit, 50 MSa/s, 64 K data point arbitrary waveforms
• AM, FM, PM, ASK, FSK and PSK modulation types
• Ramp, triangle, pulse and DC waveforms
• 14-bit, 50 MSa/s, 64 K data point arbitrary waveforms
• AM, FM, PM, ASK, FSK and PSK modulation types
R&S®SMBV100B
Generator
• Frequency range from 8 kHz to 3 GHz or 6 GHz
• Ultra-high output power up to +33 dBm
• 1 GHz modulation bandwidth with high accuracy
• Ultra-high output power up to +33 dBm
• 1 GHz modulation bandwidth with high accuracy
M8199B keysight
Arbitrary Waveform Generator
• Analog bandwidth over 80 GHz
• Continuous sampling rate: 200 to 256 GSa/s
• 1 MSa waveform memory per channel
• Continuous sampling rate: 200 to 256 GSa/s
• 1 MSa waveform memory per channel
M8199A keysight
Arbitrary Waveform Generator
• Up to 70 GHz analysis bandwidth
• Built-in frequency and phase response calibration provides a clean output signal
• 6 Effective Number of Bits (ENOB), DC to 50 GHz frequency range, Fs 100 GSa/s
• Inherent jitter < 75 fs
• Built-in frequency and phase response calibration provides a clean output signal
• 6 Effective Number of Bits (ENOB), DC to 50 GHz frequency range, Fs 100 GSa/s
• Inherent jitter < 75 fs
M8190A keysight
Arbitrary Waveform Generator
• Variable sampling rates from 125 MSa/s to 8/12 GSa/s
• Spurious-free dynamic range (SFDR) up to 90 dBc typical
• Arbitrary waveform memory up to 2 GSa per channel for advanced sequence generation
• Analog bandwidth up to 5 GHz
• Spurious-free dynamic range (SFDR) up to 90 dBc typical
• Arbitrary waveform memory up to 2 GSa per channel for advanced sequence generation
• Analog bandwidth up to 5 GHz
M8192A keysight
Arbitrary Waveform Generator
• Up to 6 M8190A AWG modules or 12 independent channels to generate complex signal scenarios
• Up to 4 M8051A and 1 M8041A BERT modules, or 10 independent channels
• Up to 4 M8051A and 1 M8041A BERT modules, or 10 independent channels
M8197A keysight
Arbitrary Waveform Generator
• One trigger input triggers up to 4 M8195A modules with defined time delay
• 2 ps double-checkable inter-module offset at all sampling rates
• 50 fs inter-module offset resolution
• 2 ps double-checkable inter-module offset at all sampling rates
• 50 fs inter-module offset resolution
M8196A keysight
Arbitrary Waveform Generator
• Sampling rates up to 92 GSa/s with 8-bit vertical resolution
• 32 GHz analog bandwidth
• Amplitude up to 1 Vpp (single-ended), 2 Vpp (differential)) with a voltage window of -1.0 to +2.5 V
• 32 GHz analog bandwidth
• Amplitude up to 1 Vpp (single-ended), 2 Vpp (differential)) with a voltage window of -1.0 to +2.5 V
