General electronic instruments

- Power accuracy: ± (0.1% of reading + 0.05% of range)
- Bandwidth: DC, 0.1Hz ~ 100KHz
- Simultaneous measurement of all parameters

General electronic instruments

- Measurement accuracy: ± (0.1% of reading + 0.05% of range)
- Bandwidth: DC,0.5Hz-100KHz
- Voltage range: 15~1000V
- Current Wide Range: 0.25-5A
- Up to 50th harmonic measurement
- Three power measurement channels

General electronic instruments

- High power accuracy: ± (0.1% of reading + 0.05% of range)
- 3 power measurement channels, can be flexibly selected according to the actual application scenario
- Bandwidth: DC, 0.5Hz-100KHz
- Maximum voltage measurement range 1500V, maximum current measurement range 50A

General electronic instruments

• Thermal cycle time: 1 to 10 seconds (adjustable)
•  Thermal cycle range: 0°C to 60°C
•  Analogue Output Ports

General electronic instruments

• Easy-to-view color display
• USB port for data storage
• Measurement module "hot-swap" function
• Remote monitoring and measurement via LAN

General electronic instruments

• 500 MHz to 13.5 GHz operating rates
• Clock generation and distribution from a single instrument
• Jitter injection in the range of 1 Hz to 100 MHz with adjustable amplitude

General electronic instruments

• Blocking Configuration
• 002 - Two input channels - 012 - FC connector
• 051 - Rear Panel Connector
• 109 - 1280-1650nm 9/125um Singlemode
• 224 - 24 Output Channels

General electronic instruments

• DC, RF and optical switching capabilities
• Supports the industry's widest range of signals
• Easy integration with digital multimeters and source instrumentation

General electronic instruments

• Fast single-connection measurements of PMD, CD, GD, PDL and IL with improved specifications
• Leading GD repeatability over a wide loss dynamic range
• Outstanding narrow-band device measurement resolution
• Wavelength operating range: 1260 - 1640 nm (O to L band)
