Network Analyzer
Network Analyzer
ZNH R&S
Network Analyzer
• Frequency range from 30 kHz to 4/8/18/26.5 GHz
• Base instrument performs single-port cable and antenna measurements
• Base instrument performs S-parameter (S11, S12, S21, S22) measurements
• 100 dB (typical) dynamic range for filter and antenna isolation measurements
• Anti-reflective display, small form factor, rugged enclosure (IP51)
• Base instrument performs single-port cable and antenna measurements
• Base instrument performs S-parameter (S11, S12, S21, S22) measurements
• 100 dB (typical) dynamic range for filter and antenna isolation measurements
• Anti-reflective display, small form factor, rugged enclosure (IP51)
ZNL R&S
Network Analyzer
• Wide frequency range from 5 kHz to 20 GHz
• Optional spectrum analysis and power probe support available up to 26.5 GHz
• Continuous wave signal generator spectrum analysis option
• Cost-effective, portable (battery-powered option), accurate, versatile
• Optional spectrum analysis and power probe support available up to 26.5 GHz
• Continuous wave signal generator spectrum analysis option
• Cost-effective, portable (battery-powered option), accurate, versatile
ZNB R&S
Network Analyzer
• Frequency range from 9 kHz to 43.5 GHz
• Two or four ports
• Wide dynamic range up to 140 dB
• Short scan time, 401 points in 4 ms
• Wide power sweep range of 98 dB
• Two or four ports
• Wide dynamic range up to 140 dB
• Short scan time, 401 points in 4 ms
• Wide power sweep range of 98 dB
ZNBT R&S
Network Analyzer
• Frequency range: 9 kHz to 8.5 GHz, or 100 kHz to 20/26.5/40 GHz
• Up to 24 ports with full phase reference receivers
• Up to 140 dB dynamic range
• Scan times as short as 1.7 ms (R&S®ZNBT8) and 2.7 ms (other models)
• Up to 24 ports with full phase reference receivers
• Up to 140 dB dynamic range
• Scan times as short as 1.7 ms (R&S®ZNBT8) and 2.7 ms (other models)
ZVA R&S
Network Analyzer
• System frequency range: 10 MHz to 110 GHz
• Dynamic range up to 130 dB (typical)
• Two test ports, 1.0 mm positive
• R&S®ZVA67 base unit can be used as a stand-alone unit
• Dynamic range up to 130 dB (typical)
• Two test ports, 1.0 mm positive
• R&S®ZVA67 base unit can be used as a stand-alone unit
ZNA R&S
Network Analyzer
• 10 MHz to 26.5/43.5/50/67 GHz (R&S®ZNA26/43/50/67);
• Available in dual- or quad-port models
• Outstanding RF performance
• Up to four integrated signal sources
• Unique and intuitive touch-only operation
• Available in dual- or quad-port models
• Outstanding RF performance
• Up to four integrated signal sources
• Unique and intuitive touch-only operation
ZNB20 R&S
Network Analyzer
• Frequency range from 9 kHz to 43.5 GHz
• Two or four ports
• Wide dynamic range up to 140 dB
• Short scan time, 401 points in 4 ms
• Wide power sweep range of 98 dB
• Two or four ports
• Wide dynamic range up to 140 dB
• Short scan time, 401 points in 4 ms
• Wide power sweep range of 98 dB
