M8195A keysight
Arbitrary Waveform Generator
• Sampling rates up to 65 GSa/s
• High channel density: 1, 2 or 4 channels per module, up to 16 channels on 4 modules can be synchronized using the M8197A multi-channel synchronization module
• Built-in frequency and phase response calibration
• High channel density: 1, 2 or 4 channels per module, up to 16 channels on 4 modules can be synchronized using the M8197A multi-channel synchronization module
• Built-in frequency and phase response calibration
MP2100B Anritsu
BERT
• All-in-one built-in 4-channel BERT and sampling oscilloscope
• Bit Error Rate (BER) 4-channel simultaneous measurement
• High quality waveform PPG (1 ps rms jitter)
• High input sensitivity (10 mVp-p minimum input sensitivity)
• Bit Error Rate (BER) 4-channel simultaneous measurement
• High quality waveform PPG (1 ps rms jitter)
• High input sensitivity (10 mVp-p minimum input sensitivity)
M9502A keysight
Arbitrary Waveform Generator
- 2 Slots for AXIe Instrument Modules
- Embedded AXIe System Module
- High power, 200W per slot with heat sinks
- Embedded AXIe System Module
- High power, 200W per slot with heat sinks
N1077B Keysight
Optical/Electrical Clock Recovery
• 125 MBd to 64 GBd data rate range (continuous) on electrical and optical NRZ and PAM4 data signals
• Standards-compliant clock recovery (“Golden PLL”) with adjustable peaking and loop bandwidth to 20 MHz
• Lock onto degraded signals (“closed eyes”) using an built-in equalizer (Option EVA)
Gain insight into root cause(s) for jitter using Jitter Spectrum Analysis (Option JSA)
• Perform compliant PLL bandwidth and peaking measurements using N1010300A FlexPLL Application software and N1081PLCA PCI Express PLL Test Application
• Standards-compliant clock recovery (“Golden PLL”) with adjustable peaking and loop bandwidth to 20 MHz
• Lock onto degraded signals (“closed eyes”) using an built-in equalizer (Option EVA)
Gain insight into root cause(s) for jitter using Jitter Spectrum Analysis (Option JSA)
• Perform compliant PLL bandwidth and peaking measurements using N1010300A FlexPLL Application software and N1081PLCA PCI Express PLL Test Application
M8040A keysight
BERT
• PAM4 signal data rates from 2 to 64 Gbaud
• True real-time PAM4 BER detection capability with data rates up to 58 Gbaud
• Built-in de-emphasis, analyzer equalization and clock recovery
• True real-time PAM4 BER detection capability with data rates up to 58 Gbaud
• Built-in de-emphasis, analyzer equalization and clock recovery
M8057A keysight
BERT
M8057A keysight BER (Bit Error Rate) Measurement 64G Baud
M9505A keysight
Arbitrary Waveform Generator
• 5 slots for AXIe instrument modules
• Embedded AXIe System Module
• High power, 200W heat dissipation capability/slot
• Gigabit LAN connection to each module slot
• Embedded AXIe System Module
• High power, 200W heat dissipation capability/slot
• Gigabit LAN connection to each module slot
E4809A Agilent
BERT
• Parallel BER Tester
• 81200: Configurable for 675 Mb/s to 2.7 Gb/s analysis
• 81250: Configurable for 675 Mb/s to 45 Gb/s analysis
• Modular BER test platform
• Generates and analyzes PRWS, PRBS and user-defined patterns
• 81200: Configurable for 675 Mb/s to 2.7 Gb/s analysis
• 81250: Configurable for 675 Mb/s to 45 Gb/s analysis
• Modular BER test platform
• Generates and analyzes PRWS, PRBS and user-defined patterns
U2761A keysight
Generator
• 20 MHz sine and square waves
• Ramp, triangle, pulse and DC waveforms
• 14-bit, 50 MSa/s, 64 K data point arbitrary waveforms
• AM, FM, PM, ASK, FSK and PSK modulation types
• Ramp, triangle, pulse and DC waveforms
• 14-bit, 50 MSa/s, 64 K data point arbitrary waveforms
• AM, FM, PM, ASK, FSK and PSK modulation types
