BERT

• Data output: differential or single-ended
• Amplitude: 0.5 to 1.8V pp
• Conversion time (20%-80%): 90ps typical @ ECL, LVDS

BERT

• 1 GHz (upgradeable)
• 4 analog channels
• 3-in-1 instrumentation: oscilloscope, logic analyzer and protocol analyzer

BERT

• 1 GHz (upgradeable)
• 4 analog channels
• 3-in-1 instrumentation: oscilloscope, logic analyzer and protocol analyzer

BERT

• BER test range 0.1 Gbit/s to 32.1 Gbit/s
• BER test range up to 64.2 Gbit/s with external MUX/DEMUX
• High quality (12 ps rise/fall time) and low jitter (8 ps p-p) PPG waveform up to 3.5 Vp-p
• Ultra-high sensitivity BER analyzer (10 mV typical)

Waveform Generators

• 33500U for 1 and 2 channels
• Stability to 0.1 ppm

Waveform Generators

• Faster throughput and longer uptime
• Excellent output power allows it to perform basic component testing and receiver function verification

Waveform Generators

• USB, GPIB and LAN (LXI) interfaces available
• 10 MHz sine and square waveforms
• Ramp, triangle, noise, pulses with variable edges, DC waveforms
• AM, FM and PWM, linear and logarithmic sweeps, and burst pulses

Arbitrary Waveform Generator

• 120 GSa/s sampling rate
• Capable of generating arbitrary signals with frequency components up to 50 GHz
• Cross-module synchronization
• 8-bit vertical resolution

Waveform Generators

• 500 MSa/s, 16-bit, 200 MHz bandwidth
• High quality output signal with low phase noise
• Up to 2 GB of on-board RAM (~1 GSa)
