Data Acquisition/Module

- 3-slot mainframe with USB and LAN ports
- 6 1/2-bit (22 bit) built-in digital multimeter that can scan up to 250 channels per second
- 8 plug-in switch and control modules available

Tunable Laser System Source

- 200nm/s fast scanning
- Line width < 60kHz
- < 1/10 frequency fluctuation (vs. conventional models)

Optical Spectral Analyzer

- Wavelength range: 1200 - 1650 nm
- High wavelength resolution: 5pm
- High wavelength accuracy: ±5pm
- Dynamic range: 65dB
- High stray light rejection ratio: 80dB

Optical Spectral Analyzer

• Three available models for short wavelength range applications: Standard, High Resolution, Limited
• Wavelength Range: 350 - 1200 nm (all models)
• Max Safe Input Power: +20 dBm (550 to 1100 nm) +10 dBm (400 to 550 nm) (total input power)

Optical Spectral Analyzer

• Wavelength range: 350 to 1200nm
• Wavelength accuracy: ±0.05 nm
• Wavelength resolution: 0.02 to 10 nm and 0.01nm (400 to 470nm)
• Max safe input power: +20 dBm
• Level sensitivity: -80 dBm
• Dynamic range: ≧60dB

Tunable Laser System Source

• Highest measurement range through low spontaneous source emission (low SSE), Signal to SSE Ratio >70 dB/nm
• Variable sweep speed up to 80 nm/s
• Wide tuning range units to cover all transmission bands: 1260 nm – 1640 nm
• Built-in wavelength meter with excellent wavelength accuracy ±3.6 pm
• High optical output power up to +9 dBm with built-in high performance 60 dB attenuator

Optical Spectral Analyzer

・Lineup of 3 models [Standard, Extended and Limited]
・Covers wavelengths
1200 to 2400 nm [Standard, and Limited]
1000 to 2500 nm [Extended ]

Arbitrary Waveform Generator

- 2 Slots for AXIe Instrument Modules
- Embedded AXIe System Module
- High power, 200W per slot with heat sinks

DC Power Supply

• Voltage up to 1200V
• Wide range of high voltage or high current models available
• Highly visible vacuum fluorescent display (VFD)
• Switchable ON/OFF control of outputs
