Network Analyzer
Other
81609A keysight
Tunable Laser System Source
• Wavelength: 1240-1380 nm or 1340-1495 nm or 1450-1650 nm or 1490-1640 nm
• Tuning time: 300 ms for a 1 nm step
• Max. power: > +12 dBm peak typ. (Options 114, 116, 216) or > +13 dBm peak typ. (Option 113)
• Signal to SSE ratio: ≥ 75 dB/nm typical
• Absolute wavelength accuracy: ±10 pm typical
• Tuning time: 300 ms for a 1 nm step
• Max. power: > +12 dBm peak typ. (Options 114, 116, 216) or > +13 dBm peak typ. (Option 113)
• Signal to SSE ratio: ≥ 75 dB/nm typical
• Absolute wavelength accuracy: ±10 pm typical
N7779C keysight
Tunable Laser System Source
• Wavelength: 1240-1380 nm or 1340-1495 nm or 1450-1650 nm or 1490-1640 nm
• Sweep speeds: up to 200 nm/s, bidirectional
• Max. power: > +12 dBm peak (Options 114, 116, 216) or > +13 dBm peak (Option 113)
• Sweep speeds: up to 200 nm/s, bidirectional
• Max. power: > +12 dBm peak (Options 114, 116, 216) or > +13 dBm peak (Option 113)
AQ6317C ando
Spectral Analyzer
• High wavelength resolution Maximum wave length resolution: 15 pm.
• Wide dynamic range Over 70 dB at peak +/-0.4 nm Over 60 dB at peak +/-0.2 nm.
• Wide dynamic range Over 70 dB at peak +/-0.4 nm Over 60 dB at peak +/-0.2 nm.
N7788B keysight
Other
• Highest accuracy through a single scan: no need to calculate the average over several scans
• High measurement speed
• Complete measurement in the C/L band in less than 10 seconds (no need to wait for multiple averages)
• Stability independent of fibre movement/vibration and drift
• High measurement speed
• Complete measurement in the C/L band in less than 10 seconds (no need to wait for multiple averages)
• Stability independent of fibre movement/vibration and drift
N7783B keysight
Other
• Thermal cycle time: 1 to 10 seconds (adjustable)
• Thermal cycle range: 0°C to 60°C
• Analogue Output Ports
• Thermal cycle range: 0°C to 60°C
• Analogue Output Ports
N7782B Keysight
Other
• Accurate polarisation extinction ratio measurements up to 50 dB in the PMF
• Aligns PMF to laser signal using recommended full polarisation determination methods
• Supports automated testing of fibre stress using the N7783B thermal cycling device
• Easy-to-use graphical software for real-time display of results
• Aligns PMF to laser signal using recommended full polarisation determination methods
• Supports automated testing of fibre stress using the N7783B thermal cycling device
• Easy-to-use graphical software for real-time display of results
AQ6150B Yokogawa
Wavelength meter
• DFB Laser Calibration for Optical Amplification Measurement Systems
• Tunable Laser Calibration for Passive Component Measurement Systems
• Highly Accurate Tunable Laser Adjustment and Detection
• Measurement of optical transceiver and transponder modulation signals
• Measurement of all channels of 40G and 100G optical transceivers via WDM technology
• Tunable Laser Calibration for Passive Component Measurement Systems
• Highly Accurate Tunable Laser Adjustment and Detection
• Measurement of optical transceiver and transponder modulation signals
• Measurement of all channels of 40G and 100G optical transceivers via WDM technology
