DSOZ334A Keysight
Oscilloscope
• 33 GHz real-time bandwidth (scalable to 63 GHz)
• 4-channel 80 GSa/s sampling rate
• Up to 2 Gpts deep memory (50 Mpts per channel standard) to support additional data acquisition
• 4-channel 80 GSa/s sampling rate
• Up to 2 Gpts deep memory (50 Mpts per channel standard) to support additional data acquisition
N1090A Keysight
Oscilloscope
• High sensitivity optical channel with < 1 µW noise
• Optical reference receiver meets industry specifications for verification of compliance with standards
• Powerful Flex-DCA interface for comprehensive photoeye diagram analysis
• Optical reference receiver meets industry specifications for verification of compliance with standards
• Powerful Flex-DCA interface for comprehensive photoeye diagram analysis
DSA8200 Tektronix
Oscilloscope
• Up to 4 true differential channels
• High bandwidth (50 GHz) time domain reflectometer
• IConnect® Signal Integrity
• Serial Data Network Analysis (SDNA)
• High bandwidth (50 GHz) time domain reflectometer
• IConnect® Signal Integrity
• Serial Data Network Analysis (SDNA)
N1000A Keysight
Oscilloscope
• Test bandwidth > 110 GHz
• Jitter as low as 50 fs
• Noise down to 275 uV.
• Sampling rates up to 250 kSa/s
• Jitter as low as 50 fs
• Noise down to 275 uV.
• Sampling rates up to 250 kSa/s
UXR0134A keysight
Oscilloscope
• 13 GHz Bandwidth
• 4 full bandwidth channels
• 10-bit ADC
• 128 GSa/s sampling rate on all channels
• Up to 2 Gpts of memory
• 4 full bandwidth channels
• 10-bit ADC
• 128 GSa/s sampling rate on all channels
• Up to 2 Gpts of memory
MXR608A keysight
Oscilloscope
• Provides 6 GHz bandwidth on 8 analog channels
• Effective Number of Bits (ENOB) up to 9.0
• Noise as low as 43 µV
• Maximum memory depth up to 1.6 G points
• Effective Number of Bits (ENOB) up to 9.0
• Noise as low as 43 µV
• Maximum memory depth up to 1.6 G points
MSO9404A keysight
Oscilloscope
• 4 GHz bandwidth
• 4 analog channels and 16 digital channels
• 3-in-1 instrumentation: oscilloscope, logic analyzer and protocol analyzer
• 4 analog channels and 16 digital channels
• 3-in-1 instrumentation: oscilloscope, logic analyzer and protocol analyzer
EXR258A keysight
Oscilloscope
• 2.5 GHz bandwidth available on all 8 channels
• Faster test speeds through ASIC technology
• Effective Number of Bits (ENOB) up to 9.0 and noise as low as 43 µV ensure accurate and reliable measurements
• Faster test speeds through ASIC technology
• Effective Number of Bits (ENOB) up to 9.0 and noise as low as 43 µV ensure accurate and reliable measurements
DSAX93204A keysight
Oscilloscope
• 33 GHz analog bandwidth
• 80 GSa/s sampling rate, 2 channels
• 40 GSa/s sampling rate, 4 channels
• Measurement noise floor (<100 fS)
• 80 GSa/s sampling rate, 2 channels
• 40 GSa/s sampling rate, 4 channels
• Measurement noise floor (<100 fS)
