Oscilloscope

• High sensitivity with < 5 µW noise
• Ultra-fast throughput with sampling rates up to 250 kHz
• Accurate high-speed data analysis with jitter < 200 fs

Oscilloscope

• Retrieves clock and data from optical signals
• Sensitivity < -27 dBm
• 2488 Mb/s rate

Oscilloscope

• 1 GHz (upgradeable)
• 4 analog channels
• 3-in-1 instrumentation: oscilloscope, logic analyzer and protocol analyzer

Oscilloscope

• 500 MHz
• 4 analog channels and 16 digital channels
• 8.5-inch WVGA display makes it easy to view signals
• Up to 4 Mpts of memory to capture more data

Oscilloscope

• Bandwidth: 60 MHz
• 2 channels plus external triggers
• 1 GS/s sampling rate on all channels
• Record length: 2.5 kpts

Oscilloscope

• Bandwidth: 200 MHz to 2 GHz
• Sampling rate: 5 Gsample/s
• Maximum storage depth: 200 Msample
• Vertical resolution: up to 16 bits

Oscilloscope

• Bandwidth: 60 MHz to 500 MHz
• Sample rate: up to 5 Gsample/s
• Storage depth: 500 kpts maximum, 50 Mpts segmented storage
• ADC resolution: 10 bits
• Isolated channels (CAT IV 600 V (RMS)/CAT III 1000 V (RMS))

Oscilloscope

• Bandwidth: 50 MHz to 300 MHz
• Maximum sampling rate: 2 Gsample/s
• Maximum memory depth: 2 Msample

Oscilloscope

• Bandwidth: 100 MHz to 1 GHz
• Sample rate: 5 Gsample/s maximum
• Memory depth: 80 Msample maximum
• ADC resolution: 10 bits
