86100C Agilent
Oscilloscope
• Oscilloscope bandwidth of over 80 GHz ensures the most accurate waveform measurements
• Eye diagram analyzer for optical and electrical transmitter conformance testing at >40 Gb/s
• Eye diagram analyzer for optical and electrical transmitter conformance testing at >40 Gb/s
N1092E keysight
Oscilloscope
• Ultra-fast throughput with sampling rates up to 250 kHz
• Accurate high-speed data analysis with jitter < 200 fs
• Compact design with smaller form factor
• Accurate high-speed data analysis with jitter < 200 fs
• Compact design with smaller form factor
N1092D keysight
Oscilloscope
• High sensitivity with < 5 µW noise
• Ultra-fast throughput with sampling rates up to 250 kHz
• Accurate high-speed data analysis with jitter < 200 fs
• Ultra-fast throughput with sampling rates up to 250 kHz
• Accurate high-speed data analysis with jitter < 200 fs
N1092C keysight
Oscilloscope
• > 40 GHz optical channel bandwidth (option 40A), 50 GHz electrical channel bandwidth
• FC/PC and 2.4 mm input types
• High sensitivity with background noise of only 5 µW (optical), 310/600 µV (electrical)
• FC/PC and 2.4 mm input types
• High sensitivity with background noise of only 5 µW (optical), 310/600 µV (electrical)
N1092B keysight
Oscilloscope
• High sensitivity with < 5 µW noise
• Ultra-fast throughput with sampling rates up to 250 kHz
• Accurate high-speed data analysis with jitter < 200 fs
• Ultra-fast throughput with sampling rates up to 250 kHz
• Accurate high-speed data analysis with jitter < 200 fs
83446A Agilent
Oscilloscope
• Retrieves clock and data from optical signals
• Sensitivity < -27 dBm
• 2488 Mb/s rate
• Sensitivity < -27 dBm
• 2488 Mb/s rate
DSO9104A Keysight
Oscilloscope
• 1 GHz (upgradeable)
• 4 analog channels
• 3-in-1 instrumentation: oscilloscope, logic analyzer and protocol analyzer
• 4 analog channels
• 3-in-1 instrumentation: oscilloscope, logic analyzer and protocol analyzer
MSOX3054A Agilent
Oscilloscope
• 500 MHz
• 4 analog channels and 16 digital channels
• 8.5-inch WVGA display makes it easy to view signals
• Up to 4 Mpts of memory to capture more data
• 4 analog channels and 16 digital channels
• 8.5-inch WVGA display makes it easy to view signals
• Up to 4 Mpts of memory to capture more data
TDS210 Tektronix
Oscilloscope
• Bandwidth: 60 MHz
• 2 channels plus external triggers
• 1 GS/s sampling rate on all channels
• Record length: 2.5 kpts
• 2 channels plus external triggers
• 1 GS/s sampling rate on all channels
• Record length: 2.5 kpts
