Oscilloscope

• Provides 6 GHz bandwidth on 8 analog channels
• Effective Number of Bits (ENOB) up to 9.0
• Noise as low as 43 µV
• Maximum memory depth up to 1.6 G points

Oscilloscope

• 4 GHz bandwidth
• 4 analog channels and 16 digital channels
• 3-in-1 instrumentation: oscilloscope, logic analyzer and protocol analyzer

Oscilloscope

• 2.5 GHz bandwidth available on all 8 channels
• Faster test speeds through ASIC technology
• Effective Number of Bits (ENOB) up to 9.0 and noise as low as 43 µV ensure accurate and reliable measurements

Oscilloscope

• 33 GHz analog bandwidth
• 80 GSa/s sampling rate, 2 channels
• 40 GSa/s sampling rate, 4 channels
• Measurement noise floor (<100 fS)

Oscilloscope

• 63 GHz real-time bandwidth
• 80 GSa/s sampling rate, 4 channels
• 160 GSa/s sampling rate, 2 channels

Network Analyzer

• Frequency range: 9 kHz to 4.5 GHz
• Flexible, high-performance compact VNAs
• Wide choice of measurement applications for in-depth analysis of RF test results

Microwave Analyser

• Standard models include cable and antenna analyzers
• Expand analyzer capabilities with optional tools such as VNA, spectrum analyzer, built-in power meter and vector voltmeter

Microwave Analyser

• 44 GHz maximum frequency
• Simultaneous measurement of DTF and TDR in a single scan
• Simultaneous measurement of all 4 S-parameters
• Lightweight at only 7.1 pounds

Network Analyzer

• Full dual-port VNA, time domain reflectometer and other instruments
• Simultaneous measurement of all 4 S-parameters
• Dynamic range up to 90 dB
