Optical Spectral Analyzer

• Three available models for short wavelength range applications: Standard, High Resolution, Limited
• Wavelength Range: 350 - 1200 nm (all models)
• Max Safe Input Power: +20 dBm (550 to 1100 nm) +10 dBm (400 to 550 nm) (total input power)

Optical Spectral Analyzer

• Wavelength range: 350 to 1200nm
• Wavelength accuracy: ±0.05 nm
• Wavelength resolution: 0.02 to 10 nm and 0.01nm (400 to 470nm)
• Max safe input power: +20 dBm
• Level sensitivity: -80 dBm
• Dynamic range: ≧60dB

Tunable Laser System Source

• Highest measurement range through low spontaneous source emission (low SSE), Signal to SSE Ratio >70 dB/nm
• Variable sweep speed up to 80 nm/s
• Wide tuning range units to cover all transmission bands: 1260 nm – 1640 nm
• Built-in wavelength meter with excellent wavelength accuracy ±3.6 pm
• High optical output power up to +9 dBm with built-in high performance 60 dB attenuator

Optical Spectral Analyzer

・Lineup of 3 models [Standard, Extended and Limited]
・Covers wavelengths
1200 to 2400 nm [Standard, and Limited]
1000 to 2500 nm [Extended ]

Oscilloscope

• One 90 GHz (standard)/120 GHz (optional) optical channel
• Jitter as low as 90 fs
• Ideal for analyzing 112 GBd (224 Gbps) optical signals or any application that require ultra• wide optical receiver > 65 GHz bandwidth (-3 dBo)
• Impulse response correction (Option IRC) is a standard feature and hardware filters for standards-based rates are optional
• Protect your investment: works with both the N1000A (250 kSa/s sampling rate) and 86100D (40 kSa/s sampling rate) mainframes

Optical/Electrical Clock Recovery

• 125 MBd to 64 GBd data rate range (continuous) on electrical and optical NRZ and PAM4 data signals
• Standards-compliant clock recovery (“Golden PLL”) with adjustable peaking and loop bandwidth to 20 MHz
• Lock onto degraded signals (“closed eyes”) using an built-in equalizer (Option EVA)
Gain insight into root cause(s) for jitter using Jitter Spectrum Analysis (Option JSA)
• Perform compliant PLL bandwidth and peaking measurements using N1010300A FlexPLL Application software and N1081PLCA PCI Express PLL Test Application

Optical Spectral Analyzer

• Spectral resolution as high as 2 GHz
• Wavelength accuracy as high as ± 0.0001 nm
• Optical rejection ratio > 40 dB
• Operation available from 375 nm to 12 μm

Optical Spectral Analyzer

• Wavelength range: 350 to 1750nm
• High wavelength accuracy: ±0.05nm
• High wavelength resolution: 0.05 to 10 nm
• Wide dynamic range: 60dB (peak ±1.0nm)
• Wide level range: +20 to -80dBm
• Fast measurement: 0.5 sec. (100nm span)

Optical Spectral Analyzer

• Wide wavelength range: 350 - 1750 nm
• High wavelength resolution: 0.05 nm (full wavelength range)
• High wavelength accuracy: ±0.05 nm (633/1523 nm), ±0.2 nm (350 - 1750 nm)
• Close-in dynamic range: 60 dB (λPK ±1 nm)
• Sensitivity: -80 dBm (900 - 1600 nm), -70 dBm (400 - 900 nm)
